ANSI/TIA Category
6
Cable Type
Unshielded
Colour
Black
Type of conductor
Solid | Stuck
Built-in type of dust cover
No
Mounting
SL series faceplates and panels
Installation Note
The color is combined with black SL-style faceplates and surface mount boxes.
Socket function
Jack's upside-down face
Outlet Type
Standard
Termination blows, minimum
200 times
Completion Tool
SL Completion Tool
Completion type
IDC
Transmission standards
ANSI/TIA-568.2-D | ISO/IEC 11801, Class E
Electrical wiring
T568A | T568B
Sizes
Cutout in the panel, recommended
14.78 x 20.07 mm (0.58 x 0.79 inches)
Recommended panel thickness
1.6mm | 0.063 inches
Height
16.26 mm | 0.64 inches
Width
14.48 mm | 0.57 inches
Depth
30.48 mm | 1.2 inches
Compatible insulated conductor diameter, max
1.45mm | 0.057inch
Thickness of the contact coating
1.27 microns
Compatible conductor gauge, solid
24–22 AWG
Compatible conductor gauge, stranded
26–24 AWG
Electrical characteristics
Change in contact resistance, maximum
20 MOM
Contact resistance, maximum
100 mOhm
Rated current at temperature
1.5 A at 20 °C | 1.5 A at 68 °F
Dielectric resistance, RMS value, conductive surface
1500 V AC at 60 Hz
Dielectric resistance, RMS value, between contacts
1000 V AC at 60 Hz
Insulation resistance, minimum
500 MOM
Remote power supply
Fully supports safe power supply via LAN cables, described in the IEEE 802.3bt standard (Type 4), and meets the requirements for disconnection under electrical load prescribed by IEC 60512-99-002.
PoE durability
Supports IEEE 802.3bt Type 4 (90W) applications after 3000 cycles of plug-to-socket connection.
Rated safe voltage
150 V AC
