Compatible with H3C
SFP-25G-SR-MM850
Name
of the FS supplier
Form Factor
SFP28
The maximum data transfer rate
is 25.78 Gbit/s
Wavelength
850 nm
Max. cable distance
100m@OM4/70m@OM3
Connector
Duplex LC
MMF Media
Type of transmitter
VKSEL
Receiver Type
PIN
Transmission power
-8.4~2.4dBm
Receiver sensitivity
＜-10.3 dBm
Power Budget
1.9 dB
Receiver overload
2.4 dBm
Power consumption
≤1 W
Extinction coefficient
>2 dB
CDR (Clock and Data Recovery)
TX and RX Built-in CDR
Support RS-FEC, FC FEC
Commercial temperature range
0 to 70°C (32 to 158°F)
