Frequency range
· 2400 MHz .. 2500 MHz
· 5150 MHz .. 5850 MHz
Polarization
Vertical
The gain is 4/7 dBi
The beam width in the horizontal plane (HBW)
is 360 degrees
The beam width in the vertical plane (VBW)
is 35/17 degrees
Ellipsoid in the horizontal plane (dB)
± 1.5 dB
Wave resistance
50 Ohms
Voltage Standing Wave Coefficient (VSWR)
≤ 2.0
Maximum power
100 Watts
Connector
N-connector of the "papa" type (pin)
Location of connectors
Below
Size (diameter × length)
28 × 400 mm (1.10 × 15.75 inches)
Antenna weight
0.2 kg (0.44 lb)
Outer shell material
Fiberglass
The color of the outer shell
White
Operating temperature
–40°C .. +70°C (–40°F .. +158°F)
The working humidity
is 5% .. 95%
Degree of moisture
protection IP65
Wind resistance
35 m/s (114.8 ft/s)
Resistance to salt mist
Resistance to dousing with a normal salt jet of 96 hours (GB/T 2423.17-2008)
Application scenario
Outdoors
Installation method
Direct installation
